Ibanez
S520AH
ElectricSuperstrat
No ratings yet
Slim S-series with ash body, fast Wizard III maple neck, and Quantum humbuckers designed for comfortable high-speed playing.
Best for
RockHard RockBlues RockShred
Score
estimated from specs & owner reviews65
Overall / 100
Playability
67
Sound
68
Build
61
Value
65
Compare head-to-head
Line up the S520AH against another model — scores, specs, and a verdict, side by side.
- vsM-II Ctm Fr Black Aqua C-Burst
- vsTH-1000 Evertune See Thru Black Sunburst
- vsEC-1000 Pearl White
- vsTH-1000 Snow White
Compare with a specific model
Specifications
Suggest an edit| Brand | Ibanez |
|---|---|
| Type | Electric |
| Body wood | Ash |
| Neck wood | Wizard IIIMaple |
| Fretboard | Rosewood |
| Strings | 6 |
| Frets | 24 |
| Scale length | 25.5" |
| Pickups | Quantum (H) / Quantum (H) |
| A Width | 43mm at NUT |
| Bridge | Edge-Zero II bridge |
| Bridge pickup | Quantum (H) bridge pickupPassive/Ceramic |
| B Width | 58mm at 24F |
| C Thickness | 19mm at 1F |
| D Thickness | 21mm at 12F |
| Factory Tuning | 1E,2B,3G,4D,5A,6E |
| Fret | Jumbo frets |
| Hardware | Cosmo Black |
| Neck pickup | Quantum (H) neck pickupPassive/Ceramic |
| Neck Type | Wizard IIIMaple neck |
| Nut | Locking nut |
| Radius | 400mmR |
| Recommended Bag | IGB540-BK |
| Recommended Case | M300C |
| String Gauge | .009/.011/.016/.024/.032/.042 |
| String Space | 10.8mm |
| Top Back Body | Ash body |
