Ibanez
SR506A
BassSuperstrat
No ratings yet
A 6-string extended-range bass with okoume body, roasted maple neck, rosewood fingerboard, and Bartolini BH2 pickups for smooth, versatile tone.
Best for
Progressive MetalFusionDjentJazz
Score
estimated from specs & owner reviews65
Overall / 100
Playability
67
Sound
68
Build
61
Value
65
Compare head-to-head
Line up the SR506A against another model — scores, specs, and a verdict, side by side.
Compare with a specific model
Specifications
Suggest an edit| Brand | Ibanez |
|---|---|
| Type | Bass |
| Body wood | Okoume |
| Neck wood | Roasted Maple |
| Fretboard | Rosewood |
| Strings | 6 |
| Frets | 24 |
| Scale length | 34" |
| Pickups | Bartolini® BH2 / Bartolini® BH2 |
| A Width | 54mm at NUT |
| Bridge | MR5S bridge |
| Bridge pickup | Bartolini® BH2 bridge pickupPassive |
| B Width | 83mm at 24F |
| C Thickness | 19.5mm at 1F |
| D Thickness | 21.5mm at 12F |
| Equalizer | Ibanez Custom Electronics 3-band EQ w/EQ bypass switch (passive tone control on treble pot), 3-way Mid frequency switch |
| Factory Tuning | 1C,2G,3D,4A,5E,6B |
| Fret | Medium frets |
| Hardware | Black |
| Neck pickup | Bartolini® BH2 neck pickupPassive |
| Neck Type | SR65pc Roasted Maple/Walnut neck |
| Radius | 400mmR |
| Recommended Bag | IBB540-BK |
| Recommended Case | MB300C |
| String Gauge | .032/.045/.065/.085/.105/.130 |
| String Space | 16.5mm |
| Top Back Body | Okoume body |
